Description
Performance Features:
- The VCD PLP drive still the “all-rounder” in the D+H range but with less overall functionality.
- Popular in the New Zealand commercial office fit outs and schools due to its cost effectiveness, compact size, and reliable performance for daily ventilation.
- Compatible with awning, casement, and hopper windows, the specialist in residential and commercial buildings.
- Universal mounting brackets, for compatibility with commonly used New Zealand joinery suites including face fix or sill mounted applications, providing solutions for both retrofit and new build projects.
- Optional synchronisation allowing up to 2 drives to work in tandem on a single large or heavy window frame.
- Programable chain stroke lengths, allowing installers to limit openings for safety (e.g., falling from height applications) or maximize openings for airflow.
- Optional burglary resistant maximum locking force of 4000 N.
- W x H x D: 300mm x 30mm x 47mm
| Product Name / Model | Drive Type | Technical Specs (Power) | Force | Locking Force | Stroke |
| VCD-203-250 | Chain Drive | 24VDC / 0.35A | 200N | 2000N | 250mm |
