VCD-0204-0350-1-ACB Chain Drive (24v)

Description

Performance Features:

• The VCD drive is the “all rounder” in the D+H range. Popular in the New Zealand commercial office fit outs and schools due to its cost effectiveness, compact size, and reliable performance for daily ventilation.
• Compatible with awning, casement, and hopper windows, the specialist in residential and commercial buildings.
• Universal mounting brackets, for compatibility with commonly used New Zealand joinery suites including face fix or sill mounted applications, providing solutions for both retrofit and new build projects.
• Intelligent synchronization with BSY+ motor electronics, allows up to 8 drives to work in tandem on a single large or heavy window frame.
• Programable chain stroke lengths, allowing installers to limit openings for safety (e.g., falling from height applications) or maximize openings for airflow.
• Anti-pinch protection prevents injury or damage if an object is detected in the window’s closing path, crucial for school and public sector projects.
• Smart building integration with ACB (Advanced Communication Bus) allows the window automation to “talk” directly to the building management system for centralised control.
• W x H x D: 480 x 30 x 47mm
